Detailed configuration
Chassis CA1163P7K2L3E , CA1170PK2L7T3EA80 . Customers can also choose other chassis.

Advantages
1200 working hours warranty
Various choices of chassis
High quality hydraulic system



Model	SQ8ZK3Q	Unit
Max Lifting Moment	16	t.m
Max Lifting Capacity	8000	kg
Recommend Power Needed At Recommend Oil Flow	28	kw
Max Oil Flow of Hydraulic System	40	L/mi
Rated Pressure Of Hydraulic System	28	MPa
Oil Tank Capacity	160	L
Rotation Angle	(360°)All Rotation	。
Crane Weight	2970	kg
Installation Space	1150	mm
Choice of Chassis	CA1176PK2L9T3A95；CA1170PK2L7T3EA80；CA1240PK2L7T4EA81；HFC1202KR1K3；EQ5161GFJ7；BJ1317VNPJJ-S5；EQ5201GFJ6；CA1200PK2L7T3EA80；LZ1160LCMTDFL1250A9；BJ5317ZNPJJ-S；CA1253P7K2L11T1E ；EQ1252GFJ；ND1255B50J ；



SQ8ZK3Q Lifting capability diagram
Working radius (m)	2	4.175	5.995	7.785	9.755
Lifting capacity (kg)	8000	3700	2400	1700	1250
