Detailed configuration
Chassis CA1163P7K2L3E , CA1170PK2L7T3EA80 . Customers can also choose other chassis.

Advantages
1200 working hours warranty
Various choices of chassis
Good hydraulic system



Model	SQ6.3SK2Q/SQ6.3SK3Q	Unit
Max Lifting Capacity	6300	kg
Max Lifting Moment	15.7	T.M
Recommend Power	20	kw
Max Oil Flow of Hydraulic System	40	L/min
Max Pressure of Hydraulic System	20	MPa
Oil Tank Capacity	90	L
Rotation Angle	All Rotation
Crane Weight	2117/2270	kg
Installation Space	900	mm
Choice of Chassis	CA1163P7K2L3E ；CA1176PK2L9T3A95 ；CA1170PK2L7T3EA80；CA1140PK2L3EA80；DFL1140B；EQ1126KJ1；HFC1202KR1K3；EQ1141NBJ2；EQ5161GFJ7；BJ1317VNPJJ-S5；EQ5201GFJ6；LZ1160LCMT；DFL1250A9；BJ5317ZNPJJ-S；NXG1160D3ZAL1X；



SQ6.3SK2Q Lifting capability diagram
Working radius (m)	2.5	3.82	6.17	8.5
Lifting capacity (kg)	6300	2900	1600	1200



SQ6.3SK3Q Lifting capability diagram
Working radius (m)	2.5	3.96	6.3	8.6	11
Lifting capacity (kg)	6300	2800	1600	1200	600
