Detailed configuration
Chassis CA1140PK2L3EA80, DFL1140B；EQ1126KJ . Customers can also choose other chassis.

Advantages
1200 working hours warranty
Various choices of chassis
Long life service

Model	SQ5ZK2Q	SQ5ZK3Q	Unit
Max Lifting Moment	10.5	10.5	t.m
Max Lifting Capacity	5000	5000	kg
Recommend Power Needed At Recommend Oil Flow	18	18	kw
Max Oil Flow of Hydraulic System	25	25	L/min
Rated Pressure Of Hydraulic System	28	28	MPa
Oil Tank Capacity	90	90	L
Rotation Angle	(360°)All Rotation	(360°)All Rotation	。
Crane Weight	2011	2117	kg
Installation Space	1050	1050	mm
Choice of Chassis	CA1140PK2L3EA80；DFL1140B；EQ1126KJ1；HFC1132KR1K3；LZ1120LAPT；EQ1141NBJ2；EQ5121GFJ；EQ5201GFJ6；HN1310P29D6M3J；NXG1160D3ZAL1X；



SQ5ZK2Q Lifting capability diagram
Working radius (m)	2.1	4.44	6.2	8.01
Lifting capacity (kg)	5000	2400	1600	1050



SQ5ZK3Q Lifting capability diagram
Working radius (m)	2.1	4.54	6.3	8.11	9.92
Lifting capacity (kg)	5000	2400	1600	1050	700
