SHANTUI Motor Grader SG21-3
Our Service:

Main Parameter:
Rated power: 160/2200kW/rpm
Engine model: Cummins 6CTAA8.3-C215
Operating weight: 17000kg

Description:
Perhaps the chief selling point of these graders is the fact that the operator has extended visibility, and is even able to view all the working parts of the machine below.
This wider range of visibility contributes to the cost efficiency of the machine,getting work done more accurately and faster. And because Shantui is the nation’s construction machinery leader in manufacturing, efficiency, quality and control,these machines come off the line at a very attractive price point.
Motor grader models include the SG16-3, SG18-3 and SG21-3. All are similar in characteristics, except for the graduated engine size and power ratings. The “3” stands for 3rd generation.

ITEM		SHANTUI Motor Grader SG21-3
Engine		Cummins 6CTAA8.3-C215
Rated power (kW/rpm)		4/55
Travel speed (km/h)	Forward 1	0–5.4
	Forward 2	0–9.4
	Forward 3	0–12.2
	Forward 4	0–20.5
	Forward 5	0–25.4
	Forward 6	0–39.7
	Reverse 1	0–5.4
	Reverse 2	0–12.2
	Reverse 3	0–25.4
Dimensions (L×W×H) (mm)		9260×2600×3400
Minimum turning radius (mm)		8200
Wheel base (mm)		2155
Gradeability (°)		20
Ma×imum traction (KN)		90
Ma×imum cutting depth (mm)		500
Operating weight (kg)		17000
Blade width (mm)		3660/3965/4270
Blade height (mm)		635
Blade rotational angle (°)		360
Ma×imum lifting height (mm)		410
Blade cutting angle adjustment Range (°)		44–91
Min. ground clearance (mm)		430
Working hydraulic system pressure (MPa)		16
Brake System Pressure (MPa)		10
